FI-AMP300X2V
2 channel power amplifier with 4Ω/8Ω/ 70V/100V direct output
The FI-AMP300X2V is a state of the art 2 channel amplifier providing 300 Watts per channel at 8Ω, 600Watts per channel at 4Ωand 300Watts per channel at 70V or 100V. It provides 2 x front panel access volume control.
The FI-AMP300X2V is designed for use in a wide variety of installations: from a simple setup in a bar/ restaurant or a corporate meeting room to being a part of a larger audio system in hotel lobby.
Pairs of channels may be individually configured to run in Stereo, Parallel or Bridged mode.
Features
Applications
Specifications
- Standard 2U Class H design with 2 channels
- 300 Watts per channel at 8Ω and 70V/100V
- Intuitive, user-friendly, front panel interface
- Two channel separate balanced line inputs by XLR Female
- Two Speakon (4 contacts) and Two Phoenix output connectors
- Stereo/Parallel Mode Selection and 0.775V/1.44V Selection
- Two channel separate volume control
- Comprehensive protection and monitoring functions
- Two channel separate status indicators include signal, peak and protection
- Amplifier with delay start system, protect the speakers from shock and damage
- Class-H design for optimum efficiency
- Superior sound quality performance
- From bars, restaurants, retail stores, to corporate meeting rooms and hotel lobby
- Sound reinforcement applications with mid power density and good sounding requirements
| Output Power | |
| @ 8Ω | 2 x 300W |
| @ 4Ω | 2 x 500W |
| Bridged @ 4Ω 70V/100V | 1 x 1000W 2 x 300W |
| Other Parameters | |
| Class | H |
| Frequency response | 35 Hz to 20 KHz (+/-3dB) |
| THD + N | <-0.05% @ 8 Ω / 1 KHz |
| Slew Rate | 40V / us |
| S/N Ratio | >98 dB |
| Damping factor | >500 @ 8 Ω |
| Channel separation | >100 dB @ 8 Ω / 1 KHz |
| Input resistance | 20 KΩ (Bal.) / 10 KΩ (Unbal.) |
| Input sensitivity | 1.0 Volt |
| Protection | DC, Short circuit, Overheat, Soft start |
| Control | |
| Front: | On/ Off Switch, 2 x Volume Ctl. |
| Rear: | Ground lift, Input link mode, Bridge mode (pair) |
| Input connectors | 2 x XLR (Bal.) |
| Ouput connectors | 2 x Speakon 4 contacts (1+/1- 2+/2-) and 2 x Phoenix 3 contacts |
| Dimention | 2U - 38" |
| W | 483 mm - 19" |
| H | 90 mm – 3.5" |
| D | 410 mm – 16.1" |
| Weight | 16 Kg – 35 Lbs |
